$9,895.00
Free Shipping
*Shipments to AK and HI – Please call for a quote
18,200 SENSIBLE BTUH @ 55F.
CellarPro’s AH24Sx-EC Wine Cooling Systems. (2 Ton Nominal) is suitable for wine cellars up to 8000 cubic feet* in both commercial and residential wine cellars. The evaporator module features a powerful energy-efficient centrifugal EC fan that can handle ducting up to 0.30″wg external static pressure (equivalent to 14″ diameter using R6 insulated flex ducting, or 153 sq. inches area using R6 insulated hard ducting.)
CellarPro AH24Sx-EC Air Handler Wine Cooling Systems (P/N 32033). Our Split Wine Cooling Systems is rated for exterior usage and designed for cellars up to 8000* cubic feet. Thus providing ducted refrigeration specifically designed for wine cellars.
All air-cooled Wine Cooling Systems equipment requires fresh air intake to dissipate the heat generated by the cooling unit. The fresh air intake CANNOT come from the wine cellar space – it must come from space outside the cellar.
Brand: CellarPro
Condensing Unit: 219 lbs
Evaporator: 156 lbs
Power/Rating:
Power:
– 208V/1PH/60HZ or 230V/1PH/60HZ ( must be specified when ordering) with dual power supplies:
– Startup Amps: 112 Amps
– Total System Watts: 2497 (not including optional Integrated Humidifier or Heater)
Warranty Resources
– Warranty Overview
To activate your warranty, you must complete and return our – Split Installation Checklist.
Click on one of the following links for more information:
CellarPro AH24Sx-EC Air Handler Wine Cooling Systems (P/N 32033). Split Wine Cooling Systems rated for indoor or exterior usage and designed for cellars up to 7500 cubic feet. This Wine Cooling Systems provides direct or ducted refrigeration specifically designed for wine cellars.
All air-cooled refrigeration equipment requires fresh air intake to dissipate the heat generated by the cooling unit. The fresh air intake CANNOT come from the wine cellar space – it must come from space outside the cellar.
Features include:
Cold Temperature
Remote Thermostats, Displays & Probes
Heating & Humidification
Condensate Pump
DID YOU KNOW?
Nobody protects your wine cellar better than CellarPro Cooling Systems! In the event your cooling unit fails and the failed components are covered by our warranty, we’ll send a replacement cooling unit to you per the terms of our Replacement Unit Program
CellarPro Replacement Unit Program
If your CellarPro cooling unit fails and the parts that failed are still covered by warranty, we’ll send a replacement cooling unit to you, as follows:
