WINE GUARDIAN DUCTED COOLING SYSTEMS
INVISIBLE CLIMATE CONTROL FOR LUXURY WINE CELLARS
Create a seamless wine cellar without visible cooling equipment. Wine Guardian Ducted Cooling Systems place the evaporator and condenser away from the cellar, delivering whisper-quiet operation, even airflow, and precise temperature and humidity control for premium residential and commercial wine collections.
- 10+ years consultant experience
- Free design & install estimates
- 2-yr product / 5-yr compressor warranty
* SHOP WINE GUARDIAN DUCTED SYSTEMS *
Wine Guardian Ducted Cooling Systems provide commercial-grade performance with discreet installation, making them the preferred choice for custom wine cellars that demand quiet operation, flexible equipment placement, and precise climate management.
Wine Guardian Cooling Units
- (4)
- (16)
- (8)
- (4)
- (13)
- (5)
- (4)
- (18)
- (2)
Price
BTU
Wine Guardian Humidifier
- (3)
Wine Cellar Cooling Questions?
Our wine cellar experts are ready to assist in finding the ideal wine-cooling unit for your cellar. Just tell us the style, size, budget, and cellar details – we’ll handle the rest.
Call Us
-

Wine Guardian D088 – Ducted Cooling Unit – 8640 BTU/H
$8,185.00 Select options -

Wine Guardian D025 – Ducted Cooling Unit – 1/4 Ton – 3300 Btu/h
$6,043.00 Select options -

Wine Guardian D050 – Ducted Cooling Unit – 1/2 Ton – 6320 BTU/H
$7,395.00 Select options -

Wine Guardian D200 – Ducted Cooling Unit – 2 Ton – 14700 BTU/H
$11,440.00 Select options -

Wine Guardian DP200 – PRO Ducted Cooling Unit – 2 TON
Select options -

Wine Guardian DP25 – PRO SENTINEL Ducted – 1/4 Ton
Select options -

Wine Guardian DP50 – PRO Ducted Cooling Unit – 1/2 Ton
Select options -

Wine Guardian DP88 – PRO Ducted Cooling Unit – 1 TON
Select options
Compare Wine Guardian ducted systems
Rows are size, columns are series. Capacities are as listed for each unit.
| D ductedSelf-contained, hidden outside the cellar | Pro DP ductedPremium series, smart connectivity | |
|---|---|---|
| 1/4 tonSmall to mid-size cellars | 3,300 BTU/h$6,043 View D025 | 3,760 BTU/hCall for price View Pro DP25 Sentinel |
| 1/2 tonMid-size wine rooms | 6,320 BTU/h$7,395 View D050 | 6,320 BTU/hCall for price View Pro DP50 |
| 1 tonLarge residential cellars | 8,640 BTU/h$8,185 View D088 | 2,700–9,600 BTU/hCall for price View Pro DP88 |
| 2 tonCommercial and very large cellars | 14,700 BTU/h$11,440 View D200 | 15,680 BTU/hCall for price View Pro DP200 |
Capacity varies with conditions where the unit is installed, so we size every system from a heatload calculation. Pro DP pricing depends on configuration; call 800-323-3130 for a quote.
How a ducted system works
The whole cooling unit sits outside the cellar, in an adjacent room, closet, attic or basement. Two short ducts carry cool air in and warm air back, so only the supply and return grilles show in the cellar.
Completely hidden
No equipment on the cellar walls, which leaves every surface for racking, glass or display.
Quiet in the cellar
The compressor and fans run in another space, so the wine room itself stays quiet.
Air- or water-cooled
Units like the D025 come in air-cooled or water-cooled versions, for locations with limited ventilation.
Ducted, split or through-the-wall?
Choose ducted if
there's a space next to the cellar that can house the unit and absorb its heat, and you want one self-contained box with no refrigerant lines to run.
Choose a split if
the heat needs to go outdoors or far from the cellar. See Wine Guardian split systems.
Choose through-the-wall if
the cellar is small and you want the simplest install. See through-the-wall units.
Square footage doesn't cool a wine cellar.
BTU load does.
Most homeowners — and unfortunately many contractors — size a cooling unit off room area alone. That approach ignores the variables that actually determine how hard a compressor has to work, and it’s the single biggest cause of oversized, undersized, and short-cycling wine cellar cooling systems.
Sizing by square feet
“My room is 200 sq ft, so I need a 5,000 BTU unit” ignores everything that actually drives heat gain into the cellar.
- Leads to units that run constantly and still can’t hold temperature
- Or units that short-cycle, causing humidity swings that damage corks and labels
- Doesn’t account for insulation, glass, or sun exposure
- Ignores ceiling height and true cubic volume
Sizing by BTU heatload
A proper heatload calculation measures the actual thermal load your cellar generates, in BTU/hr — the only number a compressor cares about.
- Accounts for wall & ceiling insulation R-value
- Factors in glass doors, windows, and sun exposure
- Includes room volume, not just floor area
- Matches ambient temperature outside the cellar
Ceiling height changes total air volume even when the floor space stays the same.
Wall, ceiling, and vapor barrier quality determine how much heat penetrates in cellar.
Glass walls and doors gain heat far faster than insulated walls, especially in direct sun.
The temperature and humidity of the space surrounding your cellar changes the load significantly.
Don't guess. Get your exact BTU requirement, free.
Send us your cellar’s dimensions, insulation, glass, and location details — our consultants calculate the precise heatload and recommend the right WhisperKOOL unit, not just the biggest one.
*Professional Installation*
Correct BTU sizing only pays off with correct installation. Our team installs WhisperKOOL self-contained, split, ducted, and ceiling-mount systems across Miami, Fort Lauderdale, and South Florida.
Free Heatload & Site Review
We calculate BTU requirements from your cellar’s real specs.
Unit Recommendation
We match you to the right WhisperKOOL series and configuration.
Professional Installation
Our technicians handle mounting, ducting, electrical, and drainage.
Warranty Registration
We complete your Product Warranty Checklist so coverage is active from day one.
Installation Services
- Self-Contained Setup
- Split System Install
- Ducted Configuration
- Ceiling Mount Install
- Electrical & Drainage
Through the wall
Indoor/outdoor condenser
Up to 25 ft from cellar
Space-saving overhead
Full coordination
Free Wine Cellar Cooling Expert Advice
Talk to a consultant with 10+ years of experience before you buy anything. We’ll review your cellar’s size, insulation, glass, and location, run the BTU heatload numbers, and recommend the right WhisperKOOL system — with no obligation.
- Free BTU heatload calculation
- Unbiased unit recommendation, not just the priciest option
- Installation quote included on request
- Support for self-contained, split, ducted & ceiling-mount systems
2Y
5Y
FL
Miami & Fort Lauderdale Showrooms
10+
Years of Experience for wine cellar projects
*FAQ's about Wine Guardian ducted cooling units*
Frequently Asked Questions
Wine cellar, Wine racks, and Wine cooling Units installation Service nationwide
Choose a single service or let us handle the whole project. Every installation is planned around your room, your collection and your climate.
Custom Wine Cellars Installation
A complete cellar built around your room, your collection and the climate where you live.
- Design consultation and 3D rendering
- Foam insulation and vapor barrier
- Racking, lighting and glass
- Cooling selected and installed with the build
Wine Racks Installation
Wine racks mounted level, anchored for the full weight of your bottles, and laid out for the collection you have now and the one you are building.
- Cable and floating wine systems
- Solid wood racks and wood cellars
- Metal wall rails, pegs and panels
- Floor-to-ceiling displays
Glass Enclosure Installation
Frameless and framed glass wine rooms, walls and doors, sealed so your cooling unit can hold temperature and humidity.
- Glass walls, doors and full enclosures
- Insulated, tempered glass options
- Gaskets and seals for climate control
- Measured and fitted to your space
- This service is only available in South Florida
Wine Cooling Units Installation
The right unit for your room’s heat load, installed so it holds steady temperature and humidity year-round.
- Free heatload calculation to size the unit
- Self-contained, ducted, split and ceiling-mount systems
- WhisperKOOL, Wine Guardian and CellarPro
- Replacement of existing cooling units
- This service is only available in South Florida

Wine Cellar Cooling Systems: Types, Sizing and How to Choose
Compare the four types of wine cellar cooling systems (through-the-wall, split, ducted and ceiling-mount), how to size them by heat load, and which fits your cellar.
