$11,999.00
Quantum Twin Series Ducted Split System are made to cool large-scale wine cellars & wine collections. The Ducted Split System is one of the highest-capacity units that we offer. This Ducted Split System includes multiple ducting options allowing for ease and flexibility of installation as well as accessibility. The air handler can be ducted up to 25 feet, creating a virtually silent cellar environment. The evaporator coil is coated with an electro-fin coating to minimize corrosion.
This cooling system is designed to operate in ambient conditions as low as -15 degrees and is crafted with the highest quality, professional-grade parts for longevity and performance. The Quantum Series is sure to give you that extra boost of cooling power and the quality you have come to expect from WhisperKOOL..
This Whisperkool Quantum SS18000 cooling system is designed to operate in ambient conditions as low as -15 degrees and is crafted with the highest quality, professional-grade parts for longevity and performance. The Quantum Series is sure to give you that extra boost of cooling power and the quality you have come to expect from WhisperKOOL.
Not sure if the Platinum Split is suitable for your wine cellar? Call 800-323-3130.
Note: A qualified HVAC-R technician is required for installation. Failure to install the system by a qualified technician will void the warranty.
*PLEASE NOTE: WhisperKOOL does not provide a smart thermostat. By selecting the 24V Thermostat Conversion Kit, you have acknowledged that the system will not be built with the standard WhisperKOOL control or liquid measuring bottle probe.
To run the equipment, you will have to source and purchase your own 24V smart thermostat. The WhisperKOOL Customer Satisfaction Team does not provide technical support for smart thermostats.
13,806 – 18,250
The BTU/h value range shown here is a theoretical number. There are often circumstances under which a cellar design may require a larger unit due to variables not accounted for in the formula. For example, these variables could be building materials (such as glass, stone, concrete, etc.)
Which do not offer the insulation capacity required to maintain the optimal cellar environment. We recommend purchasing a unit with a larger capacity to compensate for these unaccounted-for variables. An undersized unit can lead to premature failure and will most likely prevent the cellar from reaching your desired temperature.
220V H.E.
Model Quantum SS18000
Cellar Size 5,000 cu. ft.*
BTU/h (85°F condenser air intake temperature) 13806
Dimensions Evaporator: 29.5” L x 30.9” W x 19.8” H. Condenser: 31.18” L x 10.75” W x 23.25” H
Refrigerant R-134a
HP 2
Voltage Rating Evaporator: 120V (15 amp dedicated circuit required). Condenser: 220V (15 amp dedicated circuit required)
Weight (lbs) Evaporator: 96 • Condenser: 116
Amps Evaporator: 9.2 (running amps). Condenser: LRA 37/RLA 6.5/FLA 7.56
Line Set Liquid Line 3/8” OD• Suction Line (Less than 50ft. 5/8” OD) (Greater than 50ft. 3/4” OD)
Drain Line ¾” ID CPVC
Installation Evaporator can be installed up to 25 duct feet away from the cellar. The condensing unit can be installed for up to 100 line feet from the evaporator unit.
Thermostat Advanced digital display (50ft. cable), liquid-temperature-measuring bottle probe (50ft. cable)
Temp. Delta Can maintain a 55°F cellar temperature with up to 110°F condenser air intake temperature, 42V – customer supplied.
Warranty Two-year limited warranty (parts and labor)
